    150kw Api 5l Industrial Pipe Making Machine 6mm Thickness

    Ask Lasest Price
    Brand Name : ZTZG
    Model Number : ERW140 to ERW720
    Certification : CE, ISO9000
    Price : Negotiable
    Payment Terms : T/T, L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 50 Set/Sets per Year
    Delivery Time : 120 days
    • Product Details
    • Company Profile

    150kw Api 5l Industrial Pipe Making Machine 6mm Thickness

    Tube Conveyor Line Petroleum And Gas Oil Casing High-Grade Steel Pipe API 5L Standard Tube Mill


    Product Introduction

    API pipe mill is specialized for manufacturing straight welded pipe for petroleum and gas pipelines. Taking hot-rolled steel as
    raw material, it produce required pipes through cold roll forming and suitable welding methods like H.F. welding, submerged arc
    welding and so on. The whole production line adopts ‘ZTF’ forming technology.


    Product Parameter
    Product&yield
    Round Pipe
    273mm-720mm Thickness:6mm-25mm
    Square & rectangle tube
    10mm×10mm -600mm×600mm
    Thickness:0.8mm-22mm
    Length
    6m-12m Length Tolerance: ±3mm
    Production Speed
    20-120 m/min
    Production capacity
    30,000ton/year
    Consumption
    Mill installed capacity
    220 kw
    Line Area
    185m(length) ×27m (width)
    worker
    6-18 workers
    Raw Material
    Carbon Steel coil
    Carbon steel coil Q235B(ASTM GR·D,σs 230)
    Width
    25mm-2200mm Thickness: 0.8mm-22.0mm
    Coil ID
    580-700mm
    Coil OD
    Max 1800mm
    Coil Weight
    6.0t



    Application:

    For liquid delivery: water supply& drainage;
    For gas delivery: coal gas, steam and LPG;
    For structural use: piling pipe, structural pipe in the field of bridge, dock, road, and construction, etc.

    ZTZG Company Introduction

    FAQ


    Q: Are you a manufacturer?
    A: Yes, we are a manufacturer. We have 4 factories ( Machining, Assembling, Heat treatment, and Moulding ). We also have our own R&D department. Welcome to visit us.
    Q: What kind of payment term do you do?
    A: We do T/T.
    Q: What info do you need before giving me the price and proposal?
    A: Since we design individual machines based on our customer's requirements, we need your desired products' basic dimensions, including all the pipe diameter(or tube length), thickness range, usage, raw material steel grade, coil weight, and degree of automation.
    Q: What should I do if I just start a new business?
    A: Contact us immediately, we provide a free consultant for pre-sales service. Also, we can help you solve the raw material (steel coil) purchase, worker training, international market price, and more.
    Q: How do you do QA?
    A: We have a special team to do strict QA, this is one of our strengths:
    (1)Every gearbox will be tested for 8 hours with oil inside to guarantee there is no leak.

    (2)Every shaft will be inspected for centering jumpiness.
    (3)Every roller will be checked to make sure it's in the range of tolerance critical parts will be inspected for all dimensions.
    Q: Why I should choose you? what are the differences between you and other Chinese suppliers?
    A: We are concentrating on pipe-making machines for more than 20 years. We have constructed many steady trading partners in Asia, Africa, the middle east, Europe, and South America throughout the years. Our innovative designed production line and every single unit of the production line are economical and practical.

    Model List
    ModelRound pipe
    mm
    Square pipe
    mm
    Thickness
    mm
    Working spead
    m/min
    ERW20Ф8-Ф206x6-15x150.3-1.5120
    ERW32Ф10-Ф3210x10-25x250.5-2.0120
    ERW50Ф20-Ф5015x15-40x400.8-3.0120
    ERW76Ф32-Ф7625x25-60x601.2-4.0120
    ERW89Ф42-Ф8935x35-70x701.5-4.5110
    ERW114Ф48-Ф11440x40-90x901.5-4.565
    ERW140Ф60-Ф14050x50-110x1102.0-5.060
    ERW165Ф76-Ф16560x60-130x1302.0-6.050
    ERW219Ф89-Ф21970x70-170x1702.0-8.050
    ERW273Ф114-Ф27390x90-210x2103.0-10.045
    ERW325Ф140-Ф325110x110-250x2504.0-12.740
    ERW377Ф165-Ф377130x130-280x2804.0-14.035
    ERW406Ф219-Ф406170x170-330x3306.0-16.030
    ERW508Ф273-Ф508210x210-400x4006.0-18.025
    ERW660Ф325-Ф660250x250-500x5006.0-20.020
    ERW720Ф355-Ф720300x300-600x6006.0-22.020
