ERW273 high-frequency longitudinal welded pipe production line/pipe
making machine/tube mill is designed to produce
welded pipes of 114mm-273mm in OD and 3.0mm-10.0mm in wall
thickness, as well as corresponding square and
rectangular pipe.
Equipment Technology:
√ When producing round pipe, it can utilize ZTF forming technique
√ When producing square & rectangular tube, it can utilize directly
square-square (DSS) technique
Basic Technical Information of Welded Pipe Production Line
| Product&yield | Round Pipe | 114mm-273mm Thickness:3.0mm-10.0mm |
| Square & rectangle tube | 90mm×90mm -210mm×210mm Thickness:3.0mm-8.0mm |
| Length | 6m-12m Length Tolerance: ±3mm |
| Production Speed | 20-45 m/min |
| Production capacity | 40,000ton/year |
| Consumption | Mill installed capacity | 350 kw |
| Line Area | 120m(length) ×10m (width) |
| worker | 6-8 workers |
| Raw Material | Carbon Steel coil | Carbon steel coil Q235B(ASTM GR·D,σs 230) |
| Width | 280mm-690mm Thickness: 2.0mm-8.0mm |
| Coil ID | 570-640mm |
| Coil OD | Max 1800mm |
| Coil Weight | 15.0t |
Forming Process
| Round pipe | Cold roll forming process | Good roller design |
| ZTF forming process | Save at least 60% roller cost with electric control adjustment |
| Square & rectangular tube | General round-to-square process | Stable forming process |
| Round-to-square with Turks head | Good pipe quality |
| Process of directly square-to-square(DSS) | One set of roller can produce all tubes with electric control and
automatic adjustment |
Product Description
1. Uncoiler: Hydraulic tension bridle automatic adjustment.
2. Horizontal and vertical holder: Passed electroplate treatment .
Except rust protection, also can make holder more stable and can
bear more pressure.
3. Bearing: Used Needle bearing and cone bearing.
4. Welding : High configuration Plasma and Quasi ion welder, can
improve welding seam quality also can save more produce cost.
5. Welding equipment: Welding torch protective box, after used ,the
welding line will easy to grinding and can protect the welding line
, Have fast speed, low cost, easy grinding.
6. Grinding head: Automatic type grinding head (can manual or fully
automatic optional)
7. Cutting machine: Metal saw cutting or Band saw cutting machine.
8. All motor in the pipe making machine used Siemens brand.
single or doubel side decoiler, Forming, welding,internal weld
grinding,external weld grinding,shaping and sizing,solution
treatment ,cutting,unload stage. The machine is equipped with solid
and rigid stucture, and adopts humanized design ,easy and safe to
operate.
more than 20 years, the company focused on research and development
and production of stainless steel welded pipe equipment,
professional to provide high-end stainless steel pipe, stainless
steel industry control machine complete set of production line
equipment. pipe-maling machine product fine structure, easy
operation, stable performance and high precision finished products.
After more than 20 years of development, accumulated a wealth of
industry experience and established a good and stable technical
team, its products are exported to the Middle East, southeast Asia
countries and provinces across the country, the quality of the
product of many high-end customers recognition. pipe-maling
machine" good reputation, and its stability, precision and
durability are obtaine.
Machine Advantage:
By Just Pressing the Button
Easy to restore rolls.
2.4-3% strip width shrinkage than round square forming method, so
saving more raw materials
Simple abroach cold rolled section steel such as directly formed
channel steel, C shaped steel, Z shaped steel. The rolls
can be basically shared with directly square forming technology.
Technology Advantages
This kind of mill can produce round pipe,square and rectangular
pipe(direct to square or round to square) and some of
abroach cold rolled section steel.
1) ZTF Forming Technology Used In Produce Round Pipe
(1) Save 60% tooling cost
(2) Before the closed pore, one set of rolls can be used to produce
lots of sized round pipe within the range. All the rolls
before this section can be shared use and no need to change.
(3) Limite production time and labor cost
(4) Easy to restore rolls
(5) Convenient to restore and adjust.
2) Directly Square Forming Technics In Produce
Square&Rectangular Pipe
(1) Compared with ared with round to square forming technology,
square to square technology can make better shapes of
angles for cross section, smaller semidiameter of inner arcis,
flatter brim, regular outlooks.
(2) Ease more burden of the whole production line, especially for
the sizing section.
(3) 2.4-3% strip width shrinkage than round square forming method,
so saving more raw materials
(4) By advance multi-point bending, avoiding the axial force and
side abrasion, reducing the forming step and ensuring the
quality, meanwhile reducing power wastage and roll abrasion.
(5) By combined rolls, one set mould can be used to produce lots of
square and rectangular pipes for different specifications.
This can decrease the storage of rolls, save 80% roll costs, fasten
the bankroll turnover, shorten developing time for new lines.
3) Produce Parts Of Abroach Cold Rolled Section Steel
Simple abroach cold rolled section steel such as directly formed
channel steel, C shaped steel, Z shaped steel. The rolls can be
basically shared with directly square forming technology.
