48 - 114mm Pipe Manufacturing Equipment Customized Machinery Square Round ERW Tube Mill

Product Introduction

This high-frequency pipe production line is specialized equipment to produce high frequency straight seam welded pipes for structuralpipe and industrial pipe with Φ48mm~Φ114mm and wall thickness of 1.5~4.5mm. Through optimization design, best materials choice, andaccurately fabrication and rolls, the whole line can be reached high precision and high speed. Within suitable range of pipediameter and wall thickness, pipe production speed can be adjusted.

Basic Technical Information of Welded Pipe Production Line

Equipment advantages

√ When producing round pipe, it can utilize ZTF forming technique

√ When producing square & rectangular tube, it can utilize directly square-square (DSS) technique

Technical Flow

Scrolling up→ Uncoiling → Shear and Welding→ Spiral accumulator→ Forming → H.F. induction welding→ External burr removing→ Cooling → Sizing→ Flying saw → Run out table →Inspecting→ Packing→ Warehouse

Product Model List

Product Structure

Company Profile

Why Choose Us

Mode of Transport

ZTZG is one of three executive directors of 'China Steel Structure Association'

and one of China's top ten pipe making machinery brands.

With over 20 years of sales and R&D, ZTZG has acheived multiple China's first along with

several patents that lead the pipe making industry in China. We look foward to make

better, steadier, and more economical machines in the future.
