    ZTZG 1500x4 10 Pieces Metal Coil Slitting Machine / Automatic Steel Coil Slitting Line

    Ask Lasest Price
    Brand Name : ZTZG
    Model Number : 1500x4
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : T/T, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 200 sets/year
    Delivery Time : 120 days
    • Product Details
    • Company Profile

    ZTZG 1500x4 10 Pieces Metal Coil Slitting Machine / Automatic Steel Coil Slitting Line

    1500x4 Automatic carbon steel high speed 10 pieces Steel Coil Slitting Machine

    Products Description

    The slitting machine is also called vertical slitting line which are used to slit cold rolled steel coil,hot rolled steel coil,galvanized steel coil,silicone steel coil,stainless steel coil,aluminum coils etc into different width according to the user’s production demands and cut as well The smaller metal strips are recoiled at the end of the slitting machine by which these smaller strips are used necessarily for the next process usage in the professional field of making transformers,motors making industry,tube/pipe welding mill industry,Cold roll forming industry, ceiling drywall industry and other high-precison equipment making and metal strips making industries. According to the material slitting thickness there are thin plate or board slitting machine,media-thickness plate or board slitting machine and thick plate or board slitting machine. According to the metal materials there are copper strips slitting machine,stainless steel slitting machine,cold or hot rolled plate slitting machine,silicone steel slitting machine.

    Product Paramenters




    Steel
    coil parameters
    Material
    HR,CRS and GI
    Tensile strength
    δb≤450Mpa,δS≤260Mpa
    Steel thickness
    0.8-4mm
    Steel width
    500-1600
    Steel coil I.D
    φ480-520 mm
    Steel coil O.D
    φ1600mm(Max)
    Steel coil weight
    15T

    Slitter parameters
    knife pivot diameter
    Ф200 mm
    Knife pivot material
    40Cr
    Blades specification
    Φ200mmXφ340mmX15mm
    Blade material
    6CrW2Si
    Slit parameter
    Max slit quantity
    5 pcs (3mm) 25 pcs(0.3mm)
    Width precision
    ≤±0.05mm/2M
    Mini slit strips width
    20mm



    Other parameters
    Power
    380V/50Hz/3Ph
    Line speed
    0-100m/min
    Capacity
    210 Kw
    Whole line Dimension
    25m(L)X8m(W)
    Operator needed
    1 mechanical engineer ,2 common workers
    Line direction
    From right to left(Face to machine)
    Machine color
    White grey

    Features


    Uncoiler: gear box lubrication: concentrated thin oil lubrication
    Uncoiler, recoiler: shaft: 42CrMo forgings normalizing treatment; after rough turning, thermal refining HB290-320.
    Gearbox gear: material 20CrMoTi, rough turning thermal refining HB245-255, gear surface high frequency quenching, hardness HRC48-52. All gear tooth surface have gear grinding treatment.
    Arc plate: ZG45 cast steel, thermal refining, HB250-275, chrome plated surface polishing treatment
    Main bearings adopt imported bearings.


    ZTZG 1500x4 10 Pieces Metal Coil Slitting Machine / Automatic Steel Coil Slitting Line

    ZTZG 1500x4 10 Pieces Metal Coil Slitting Machine / Automatic Steel Coil Slitting LineZTZG 1500x4 10 Pieces Metal Coil Slitting Machine / Automatic Steel Coil Slitting LineZTZG 1500x4 10 Pieces Metal Coil Slitting Machine / Automatic Steel Coil Slitting Line


    ZTZG 1500x4 10 Pieces Metal Coil Slitting Machine / Automatic Steel Coil Slitting LineZTZG 1500x4 10 Pieces Metal Coil Slitting Machine / Automatic Steel Coil Slitting Line


    FAQ


    Q: Are you a manufacturer?
    A: Yes, we are a manufacturer. We have 4 factories ( Machining, Assembling, Heat treatment, and Moulding ). We also have our own R&D department. Welcome to visit us.
    Q: What kind of payment term do you do?
    A: We do T/T and L/C.
    Q: What info do you need before giving me the price and proposal?
    A: Since we design individual machines based on our customer's requirements, we need your desired products' basic dimensions, including all the pipe diameter(or tube length), thickness range, usage, raw material steel grade, coil weight, and degree of automation.
    Q: What should I do if I just start a new business?
    A: Contact us immediately, we provide a free consultant for pre-sales service. Also, we can help you solve the raw material (steel coil) purchase, worker training, international market price, and more.
    Q: How do you do QA?
    A: We have a special team to do strict QA, this is one of our strengths:
    (1)Every gearbox will be tested for 8 hours with oil inside to guarantee there is no leak.

    (2)Every shaft will be inspected for centering jumpiness.
    (3)Every roller will be checked to make sure it's in the range of tolerance critical parts will be inspected for all dimensions.
    Q: Why I should choose you? what are the differences between you and other Chinese suppliers?
    A: We are concentrating on pipe-making machines for more than 20 years. We have constructed many steady trading partners in Asia, Africa, the Middle East, Europe, and South America throughout the years. Our innovative designed production line and each unit of the production line practical.
