ERW Steel Tube Line High-Frequency Straight Seam Welded Pipe ERW
Tube Mill
Product Introduction
High frequency welded pipe production line is mainly used for
continuous production of straight seam welded pipe. It adopts
high-frequency induction welding, which can not only produce round
pipe but also corresponding square pipe and special-shaped pipes.
The high-frequency pipe welding machine is mainly used for the production of various
iron pipes, construction pipes, structural pipes, water pipes, oil pipes, API Pipes, and so on.
Technology
ZTZG was established in 2000, with 20 years of design and
manufacturing experience. We are:
We have the honor to get 10 plus letters patent, China Cold-Formed Steel Technology and Equipment Innovation Award,
and numerous other honors.
Theory
The straight seam welded pipe production line uses roll forming
theory to gradually shape the strip steel into a billet tube, then
through Kelvin effect and proximity effect of the high frequency
current to heat up the welding line, letting it reach the welding
temperature and finish the welding. A scraping device will then cut
off the extra burr created during the welding phase, and the heated
tube will go through the process of water cooling which lowers the
tube temperature to standard degrees. Next, another round of
roller-sizing will further shape the tube size and thickness and
let it reach the desired diameter or dimension. Lastly, the tube
will go through a rough straightening process through Turkshead and
finally come out as the finished product.
| Raw Material | Coil Material | Low Carbon Steel, Q235, Q195 |
| Width | 100~240mm |
| Thickness | 1.5~4.0mm |
| Coil ID | φ450-φ520mm |
| Coil OD | Max φ1200mm |
| Coil Weight | 1.0~3.0Tons |
| Production Capacity | Round Pipe | 32~76mm |
| Square & Rectangular Pipe | 25*25~60*60mm |
| Wall Thickness | 1.5~4.0mmmm (Round Pipe) |
| 1.5~3.0 mm(Square Pipe) |
| Speed | Max. 80m/min |
| Pipe Length | 6~12m |
| Workshop Condition | Dynamic Power | 380V, 3-phase, |
| 50Hz (depends on local facilities) |
| Control Power | 220V, single-phase, 50 Hz |
| Size of the whole line | 65m X 6m (L*W) |
Application
Mainly used in the production of round pipe, oval pipe, and
rectangular pipe.
Applications of pipe: Construction, Automotive, General Mechanical
Piping, Furniture, Agricultural, Chemical, Petroleum, Gas,
Pipeline, Structure, Scaffold. In the field of furniture,
construction, municipal facilities, and others.
Advantage
Main advantages:
High production efficiency: we choose trusted brand H.F. weder,
ensuring the pipes are welded with high speed and almost no waste
of steel material. Our roller stands are stronger and is made by
casting iron, so the precision is highly secured. Beside, the
service life is longer.
Highly automated
High strength, high speed, and stable operation improve product
quality
Reduce production losses
Save roll changing time
Low wear of rollers
