    thickness 0.4- 8.0mm Steel Coil Cutting Machine

    Ask Lasest Price
    Brand Name : ZTZG
    Model Number : 1600x4
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 200 sets/year
    Delivery Time : 120 days
    • Product Details
    • Company Profile

    thickness 0.4- 8.0mm Steel Coil Cutting Machine

    Slitting line description

    Specializing in the manufacturing of material cutting, cutting machinery and its affiliated machinery and equipment

    Engaged in scissors for many years, spacer sets, cutting, cutting machinery manufacturing experience

    The manufacturing speed of the slabbing machine is fast


    Main Parameters

    Processing Thickness0.3~4.5mm
    Processing Width600-1600mm
    Slitting Accuracy±0.15 mm
    Slitting Speed120m/min
    Coil Inner Diameter500/610 mm
    Coil Outer Diameter≤2000 mm
    Max. Slitting Numbers6-22pcs
    Slitting Coil Width≥20 mm


    Theory

    Coil-loading — Single-mandrel uncoiler — Coil-head-feeding, press & shoveling — Double-roller pinch feeding, three-roller leveling — End-cutting — Hole Accumulator(1) — Strip-aligning — Disc shearing — Scrap reeling — Hole Accumulator(2) — Pre-separator/Tensioner/length-measuring roller — Recoiling/Coils press & separator — Coils-discharging — Hydraulic control — Electric contro


    thickness 0.4- 8.0mm Steel Coil Cutting Machine


    Inspection

    The accuracy and capability of the slitting line:

    1~1.5mm±0.15mm20pcs
    1.6~3.0mm±0.15mm15pcs
    3.1~4mm±0.15mm10pcs
    Camber on strips:0.3mm/m

    ZTZG Company Introduction

    FAQ


    Q: Are you a manufacturer?
    A: Yes, we are a manufacturer. We have 4 factories ( Machining, Assembling, Heat treatment, and Moulding ). We also have our own R&D department. Welcome to visit us.
    Q: What kind of payment term do you do?
    A: We do T/T.
    Q: What info do you need before giving me the price and proposal?
    A: Since we design individual machines based on our customer's requirements, we need your desired products' basic dimensions, including all the pipe diameter(or tube length), thickness range, usage, raw material steel grade, coil weight, and degree of automation.
    Q: What should I do if I just start a new business?
    A: Contact us immediately, we provide a free consultant for pre-sales service. Also, we can help you solve the raw material (steel coil) purchase, worker training, international market price, and more.
    Q: How do you do QA?
    A: We have a special team to do strict QA, this is one of our strengths:
    (1)Every gearbox will be tested for 8 hours with oil inside to guarantee there is no leak.

    (2)Every shaft will be inspected for centering jumpiness.
    (3)Every roller will be checked to make sure it's in the range of tolerance critical parts will be inspected for all dimensions.
    Q: Why I should choose you? what are the differences between you and other Chinese suppliers?
    A: We are concentrating on pipe-making machines for more than 20 years. We have constructed many steady trading partners in Asia, Africa, the middle east, Europe, and South America throughout the years. Our innovative designed production line and every single unit of the production line are economical and practical.
