General Description
The proposed Steel Pipe Production Line is a combination of equipment installed in a line for the production of High FrequencyInduction Welded (HFIW) carbon steel tubes. The process involved is cold forming of carbon steel strip in circular shape,longitudinal welding, sizing, converting into specified shape and cutting to pre determined length. Ф127 high-frequency welded tube mill line is designed to produce round tubes with diameter of Φ48～Φ127mm with wall thickness of 1.0～4.0mm and square/rectangular tubes of corresponding size. This line utilizes roll forming to process steel strip into various shapes. Using high frequency induction heating, this line is capable of producing section material of various diameters and sizes by squeezing weld seam together into closed shape. The products conform to BS/ASTM Standard. Adopting the advantages of the equipment of the same kind at home and abroad, each element of the line is designed with new ideas. The application of advanced technology, PLC automatic control system and British Eurasia Digital speed regulating unit ensure that the production line works reliably,operates and maintains easily. Being the best production line in China, it can also compete with the advanced ones in the world.

Basic Configuration

{steel strip} --- un-coiler --- (opener & straightener & pincher & leveler) --- strip-head shearer & butt welder station --- vertical cage accumulator or horizontal spiral accumulator loop --- forming M/C (main driving unit + flattening unit + breakdown section + fin pass section +seam guiding stand + high frequency induction welding system + squeeze welding roller stand + outside scrafing unit + horizontal ironing stand) --- emulsion cooling section --- sizing M/C (main driving unit + sizing section + speed testing unit + straightener + pull-out stand) --- CNC flying saw under computer control --- conveyor table.

Why Choose us?

• Focus on motion control for 25+ years, customize equipment,Independent research and development, production and sales, no middlemen make a difference
• Many years export experience, serves hundreds clients in 60 countries
• Top engineer team, advanced production process, maximize returns for client
• 24 hours online service, excellent service system
• Smart factory full-line solution integration, providing high-quality control solutions, saving customers a lot of time and costs.

Advantages

√ High production efficiency, line speed can be up to 50m/min.
√ High yielding, the machine works stably at a high speed, which improves the yielding of products.
√ Low wastage, low unit wastage and low production cost.
√ High accuracy, diameter error is only 0.5/100 of the pipe OD
Technical Flow Of The Production Line

Parameter list
